PRODUCT DESCRIPTION
BATTERY READY FOR DC COUPLED AND AC COUPLED SYSTEMS
LEADING FUNCTIONS
– Whole home backup
– Dark start operation
– Support RSD, AFCI and RGM meter
HIGH YIELDS
– DC/AC Ratio up to 2.0
– MPP trackers up to 4
– Max. efficiency 98.5%
SYSTEM COMPATIBILITY
– DC Coupled and AC Coupled systems
– Self-consumption, Zero Export, ToU and Off-grid
– UL1741SA/SB, CA Rule 21 & HECO
SPECS |
|
|---|---|
| Power Output | 10.0kW |
| AC Voltage | 240V |
| DC Voltage | 600V |
| Maximum Short Circuit DC Input Current | 20A |
| Maximum Operation DC Input Current | 13.5A |
| Number of MPPT’s | 4 |
| MPP operating voltage window | 50-550V |
| Connectivity | RS485 |
| Display | Status LEDs |
| Cooling Method | Natural Convection |
| Number of DC Inputs | 4 |
| Connectivity Optional | WiFi/Ethernet |
| Battery Compatibility | Growatt APX battery |
| Inverter Type | Hybrid |
